产品名称： 机场专用（照明）电缆 YJVD YJYD
	产品型号： YJVD YJYD
	产品价格： 电议 特价：电议
	发布时间：2013-6-6 21:39:46
	关 注 度：5293

机场专用（照明）电缆

 (Lighting) Cable Specially Used for Airport

用途

适用于额定电压（U。/U) 3.6/6kV机场内滑行 跑道灯、跑道进入灯和其他照明和信号指示灯等 照明系统。

Appcications

The cable is applicable to the lighting system with rated voltage of (IV U) 3.6/6kV such as taxi runway lights, runway entering lights and other indicating lights for lighting and signal inside the airport.

型号及名称

Types and Designation

名称

Designation

型号

Type

铜芯辐照交联聚乙烯绝缘聚氯乙烯护套机场照明电缆

Copper-core irradiation Cross-linked Polythene Insulated PVC Sheathed Airport Lighting Cable

YJVD

铜芯辐照交联聚乙烯绝缘耐候性聚烯烃护套机场照明电缆

Copper-core irradiation Cross-linked Polythene Insulated Anti-weathering Polyolefine Sheathed Airport Lighting Cable

规格                  Specification

型号         额定电压kV  芯数         规格mm2

Type         Rating Volage Cores        Specification

YJVD         3.6/6        1       6、10

YJYD

YJYD

性能参数

耐压12kV加压5分钟 90°C绝缘电阻常数3.67MQ • km 20°C导体直流电阻

Performance

Withstanding voltage: 12V，Adding Voltage for 5 minutes

90#C Insulated Electric Resistance Constant3.67Mn • km

20°C Conductor Direct Current Resistance6mm2 ^3.0812/km

10mm2 彡 1.83'n/km

20°C Insulated Dielectric Coefficient^3.5

Medium Loss Factor^0.02

Partial Discharge ^10pC

Features

1.The        working temperature of the conductor is 90°C, 105°C and 125°C respectively, and it has strong overload protection ability.

2.The        product can effectively prevent the interference of electromagnetic field with its excellent shielding properties.

3.The        product is provided with high insulation resistance and strong corona resistance ability.

4.The        integrated insulated ability of the product is highly enhanced through introducing advanced triple extrusion technique.

5.The        product is oil resisting and refractory.

6.The        product has excellent environmental stress resisting a bility, and the cable has a long service life.

6mm2^3.08 Q/km 1 Omm2^ 1.83 0 /km ^3.5 彡 0.02 彡 lOpC

20°C绝缘介电系数 U。介质损耗 局部放电

产品特点

1、导体工作温度分别为9(TC、105°C、125'C,过 载保护能力强。

2、产品屏蔽性好，可有效防止电磁场的干扰。

3、绝缘电阻高，耐电晕能力强。

4、采用先进的三层共挤技术，提高电缆的绝缘 综合性能。

5、耐油、耐溶性。

6、耐环境应力性能较优，电缆使用寿命长。

Conductor Conductor shield Insulation Insulation shield Steel shield
