线芯＊标称截面(mm2) |
导体结构 (根数＊直径) (B/R) mm |
电缆最大外径(mm) |
参考重量(kg/km) |
||
|
ZR-JEF ZR-JEFR |
ZR-JEF ZR-JEFR |
ZR-JEF ZR-JEFR |
|
||
|
1＊1.5 |
19＊0.32/48＊0.20 |
3.2 |
3.5 |
27.5 |
|
|
1＊2.5 |
19＊0.41/51＊0.25 |
3.7 |
3.9 |
38.6 |
|
|
1＊4 |
19＊0.52/82＊0.25 |
4.6 |
5.2 |
55.5 |
|
|
1＊6 |
19＊0.65/123＊0.25 |
5.6 |
6.5 |
77.7 |
|
|
1＊10 |
48＊0.52/204＊0.25 |
7.2 |
7.8 |
132 |
|
|
1＊16 |
75＊0.52/323＊0.25 |
8.2 |
9.0 |
188 |
|
|
1＊25 |
108＊0.52/513＊0.25 |
10.2 |
11.0 |
312 |
|
|
1＊35 |
108＊0.65/722＊0.25 |
112 |
12.0 |
408 |
|
|
1＊50 |
10＊2.52/1026＊0.25 |
13.5 |
14.5 |
554 |
|
|
1＊70 |
19＊2.16/1406＊0.25 |
16.5 |
17.5 |
762 |
|
|
1＊95 |
19＊2.52/486＊0.50 |
19.0 |
20.5 |
1045 |
|
|
1＊120 |
24＊2.52/608＊0.50 |
20.0 |
22.0 |
1281 |
|
|
1＊150 |
30＊2.52/760＊0.50 |
21.0 |
24.2 |
1612 |
|
|
1＊185 |
37＊2.52/945＊0.50 |
25.0 |
28.0 |
1981 |
